Specification
Processor
-
CPU
AMD Ryzen™ 9 270 Processor
8 Cores/16 Threads
Architecture: Zen4
Base Clock: 4GHz
Max Boost Clock: Up to 5.2 GHz
Cache: 16MB L3
Process Technology: TSMC 4nm FinFET -
GPU
AMD Radeon™ 780M (RDNA 3 Architecture)
12 Compute Units
Up to 2.8 GHz -
NPU
Integrated AMD Ryzen AI Engine (XDNA architecture)
Up to 16 TOPS NPU AI performance
Total AI Performance (CPU+GPU+NPU): Up to 39TOPS
Memory & Storage
-
Memory
32GB LPDDR5 6400MT/s
(OnBoard LPDDR5)
Non-upgradable -
Storage
1TB M.2 2280 PCIe4.0×4 NVMe SSD
3 × M.2 2280 Slots
Supports M.2 NVMe PCIe4.0x4 SSD
SATA M.2 SSD Not Supported
Up to 4TB per Slot (12TB Total)
Wireless Connectivity
- WiFi WiFi 6E
- Bluetooth Bluetooth 5.2
Output
-
Video
HDMI® 2.1×1 (8K@60Hz）
2× USB4 Type-C | Up to 40Gbps Data Transfer | Supports DP 1.4 (8K@60Hz / 4K@120Hz) | Supports 100W PD Input & 15W PD Output
DP2.1×1 (8K@60Hz) - Audio 3.5mm Audio Jack ×1
Ports & Buttons
-
Ports & Buttons
2.5GbE RJ45 LAN ×2
USB 3.2 Gen 2 Type-A ×2 — Front, up to 10Gbps
USB 3.2 Gen 2 Type-A ×1 — Rear, up to 10Gbps
USB 2.0 Type-A ×1 — Rear
USB4 Type-C ×2 — Up to 40Gbps data transfer; supports DP 1.4 (8K@60Hz / 4K@120Hz); supports 100W PD input and 15W PD output
DC-IN ×1
HDMI® 2.1 ×1
DP 2.1 ×1
3.5mm Audio Jack ×1
Power Button ×1
OCuLink ×1 — Supports external GPU connectivity
Base Configuration
- Power DC 19V/6.3A, 5.5 x 2.5mm DC connector
- System Windows 11 PRO
- Dimensions 130 x 132 x 62mm
Cooling System
- Dual-fan cooling (CPU fan + system fan) + VC heat spreader, delivering up to 65W of performance
